- Size: 127cbm
- Place of Origin: XUZHOU
- Brand Name: XJCM
- Model Number: QY25
- Weight: 33250.000 kg
Table 2- 1 QY 25 Main technical parameters table in travel state
Category | Item | Unit | Value | |||
Outline Dimension Parameters | Overall length | mm | 12925 | |||
Overall width | mm | 2495 | ||||
Overall height | mm | 3870 | ||||
Axle base | 1 st axle base | mm | 1900 | |||
2 nd axle base | mm | 3700 | ||||
3 rd axle base | mm | 1350 | ||||
Tread | Front wheel (1 st axle and 2 nd axle) | mm | 2040 | |||
Rear wheel (3 rd axle and 4 th axle) | mm | 1860 | ||||
Weight Parameters | K erb weight | Total weight | kg | 33255 | ||
Front 1 st / 2 nd axle weight | kg | 6450/6450 | ||||
Rear 3 rd and 4 th axles weight | kg | 20355 | ||||
Dead weight in travel stat e | Total weight | kg | 33450 | |||
Front 1 st / 2 nd axle weight | kg | 6500/6500 | ||||
Rear 3 rd and 4 th axles weight | kg | 20450 | ||||
Power Parameters | Engine model |
| YC6A260-33 | |||
Engine Max. output power | KW/(r/min.) | 191/2300 | ||||
Engine Max. torque/Max. toque rotation speed | N.m/(r/min.) | 960/1400-1600 | ||||
Engine rated rotation speed | RPM | 2300 | ||||
Travel Parameters | Travel speed | Max. travel speed | Km/h | 80 | ||
Min. stable travel speed | Km/h | 3-5 | ||||
Turning radius | Min. turning radius | m | 22 | |||
Approach angle | ° | 27 | ||||
Departure angle | ° | 17 | ||||
Braking distance (at 30km/h) | m | ≤9 | ||||
% | 25 | |||||
Fuel consumption/100KM | l | ≈35 | ||||
Table 2- 2 QY 25 Main Technical Parameters Table in Lifting State
Max. total rated lifting load | t | 25.0 | ||||
Min. rated working radius | m | 3.0 | ||||
Turning radius at swing table tail | m | 3.22 | ||||
Max. load moment | Base boom | KN.m | 860 | |||
Fully-extended boom | KN.m | 412 | ||||
Fully-extended boom Jib | KN.m | 389 | ||||
Outrigger span | m | 5.6 | ||||
Lateral | m | 6 | ||||
Lifting height | Base boom | m | 11 | |||
Fully-extended boom | m | 40 | ||||
Fully-extended boom Jib | m | 48.2 | ||||
Boom length | Base boom | m | 10.5 | |||
Fully-extended boom | m | 40m | ||||
Fully-extended boom Jib | m | 47.3m | ||||
Jib installation angle | ° | 0, 30 | ||||
Working Speed Parameters | Boom l uffing time | Boom raising time | s | 85 | ||
s | 60 | |||||
Boom telescoping time | Boom fully-extended time | s | 165 | |||
Boom fully retracting time | s | 115 | ||||
Max. swing/slewing speed | rpm | 2 | ||||
Outriggers telescoping time | Horizontal outriggers | Extending s ynchronously | s | 25 | ||
Retracting synchronously | s | 15 | ||||
Vertical outriggers | Extending synchronously | s | 25 | |||
Retracting synchronously | s | 25 | ||||
Hoisting speed (single rope) | Main winch | Full load | m/min | 75 | ||
No load | m/min | 100 | ||||
Auxiliary winch | Full load | m/min | 75 | |||
No load | m/min | 100 | ||||
Noise limitation | External radiation | dB(A) | ≤ 116 | |||
Driver position | dB(A) | ≤ 90 | ||||
