Outline Dimension

Parameters

Overall length

mm

1 175 0

Overall width

mm

29 80

Overall height

mm

360 0

Axle base

mm

3600

Tread

mm

2500

Weight Parameters

Dead weight in travel state

Kg

2 770 0

Axle load

Front axle

Kg

12880

Rear axle

Kg

13720

Power Parameters

Engine rated output

Kw/(r/min)

16 9 /2 5 00

Engine rated torque

N.m(r/min)

900 /1 2 00 -1700

Travel Parameters

Travel speed

Max. travel speed

Km/h

40

Min. stable travel speed

Km/h

1

Turning radius

Min. turning radius

m

5.1

Min. turning radius of boom head

m

9.25

Min. ground clearance

mm

400

Approach angle

°

21

Departure angle

°

21

Braking distance (at 30km/h)

m

≤9

Max. grade ability

%

55

Max. outside noise during accelerating

dB(A)

86

Category

Items

Unit

Parameter

Main Performance Parameters

Max. total rated lifting load

t

30

Min. rated working radius

m

3

Turning radius at swing table tail

m

3.525

Max. load moment

Base boom

KN.m

920

Fully-extended boom

KN.m

560

Fully-extended boom   Jib

KN.m

380

Outrigger span

Longitudinal

m

6.08

Lateral

m

6.5

Lifting height

Base boom

m

9.6

Fully-extended boom

m

27. 9

Fully-extended boom Jib

m

3 6

Boom length

Base boom

m

9.18

Fully-extended boom

m

27.78

Fully-extended boom Jib

m

3 5.1

Jib installation angle

°

0, 30

Working Speed Parameters

Luffing time

Boom raising time

s

75

Boom descending time

s

75

Boom telescoping time

Boom fully-extended time

s

80

Boom fully retracting time

s

50

Max. swing/slewing speed

r/min

2.0

Outriggers telescoping time

Horizontal outriggers

Extending s ynchronously

s

25

Retracting synchronously

s

15

Vertical outriggers

Extending synchronously

s

25

Retracting synchronously

s

15

Hoisting speed (wire rope is at the 4 th layer)

Main winch

Full load

m/min

80

No load

m/min

85

Auxiliary winch

Full load

m/min

85

No load

m/min

90
